HIGH PERFORMANCE.
PRECISION. STABILITY.
The High Performance Series is engineered for superior performance in demanding applications, featuring variable pitch geometry to significantly reduce chatter and vibration.
All HP Series undergo a unique honing process to improve edge integrity and finish quality with specially designed core and heel geometry to enhance rigidity and minimize tool deflection for consistent, accurate results.
Choose from a broad selection of geometries, lengths, and configurations (fractional) to match your specific needs that provide dependable results with for plunging, pocketing, slotting, ramping and profiling applications.
Material: Premium: 10% micrograin carbide for enhanced strength and wear resistance
Honed Cutting Edges: All tools are honed to extend tool life and improve cutting performance
Wide Range of Sizes: Cutting diameters from 1/8" to 1" - Centre Cutting
Geometries for Every Application (Round & Weldon Shanks):
-
Square & Corner Radius End – 4 & 5 Flute
-
Ball Nose – 4 Flute
-
Long Reach Neck Relief Square & Corner Radius End – 4 Flute
-
Long Reach Neck Relief Ball Nose – 4 Flute
Versatile Configurations: Length of Cut from 7/16" to 3"
Coating Options:
-
TiALN Coated – Provides high heat resistance and extended tool life in harder materials or high-speed applications
